产品特点：
步进角1.8°
两相直流42步进电机采用两相驱动器XNFDR4进行驱动，产品法兰尺寸42mm，角度误差:±0.09°，轴向容许负载:10N，径向容许负载:25N(距安装面15mm)。
想要获得更多产品信息，请致电: 1881367658013923484902
|
型号 |
步矩角 |
电压 |
电流 |
电阻 |
电感 |
保持转矩 |
转动惯量 |
引线数 |
重量 |
机身长（L） |
|
|
单出轴 |
双出轴 |
deg |
V |
A |
Ω |
mH |
mN-m |
g-cm² |
Pin |
g |
mm |
|
SST43D1045 |
SST43D1046 |
1.8 |
6.8 |
0.57 |
12.00 |
16.0 |
294 |
33 |
4 |
230 |
34 |
|
SST43D1065 |
SST43D1066 |
1.8 |
4.9 |
0.85 |
5.75 |
8.1 |
304 |
33 |
4 |
230 |
34 |
|
SST43D1085 |
SST43D1086 |
1.8 |
3.6 |
1.13 |
3.20 |
4.9 |
312 |
33 |
4 |
230 |
34 |
|
SST43D1105 |
SST43D1106 |
1.8 |
3.0 |
1.41 |
2.10 |
3.3 |
319 |
33 |
4 |
230 |
34 |
|
SST43D1125 |
SST43D1126 |
1.8 |
2.3 |
1.70 |
1.35 |
2.3 |
322 |
33 |
4 |
230 |
34 |
|
SST43D1155 |
SST43D1156 |
1.8 |
1.9 |
2.12 |
0.90 |
1.5 |
309 |
33 |
4 |
230 |
34 |
|
SST43D2045 |
SST43D2046 |
1.8 |
8.6 |
0.57 |
15.00 |
24.0 |
420 |
56 |
4 |
290 |
40 |
|
SST43D2065 |
SST43D2066 |
1.8 |
5.1 |
0.85 |
6.00 |
11.8 |
432 |
56 |
4 |
290 |
40 |
|
SST43D2085 |
SST43D2086 |
1.8 |
3.9 |
1.13 |
3.45 |
7.1 |
422 |
56 |
4 |
290 |
40 |
|
SST43D2105 |
SST43D2106 |
1.8 |
3.4 |
1.41 |
2.40 |
4.8 |
441 |
56 |
4 |
290 |
40 |
|
SST43D2125 |
SST43D2126 |
1.8 |
2.8 |
1.70 |
1.65 |
3.6 |
456 |
56 |
4 |
290 |
40 |
|
SST43D2145 |
SST43D2146 |
1.8 |
2.3 |
1.98 |
1.15 |
2.5 |
441 |
56 |
4 |
290 |
40 |
|
SST43D2165 |
SST43D2166 |
1.8 |
2.1 |
2.26 |
0.95 |
1.8 |
424 |
56 |
4 |
290 |
40 |
